Concept 3 Part Acoustic Screen Partitioning 1.8m High
Dispatched in 10 Working Days
- Includes a set of Stabilising Feet & 2 Way Link Strip
- Finished in Silver, Black or White Aluminium, powder coated framework
- Manufactured with an 18mm solid core
- Available in 5 widths, all at 1.8m high / 5.9ft
- Concept Office Screens have 12mm acoustic foam both sides
- Available in a choice of 25 fabric colours
- Includes 3 Acoustic Panels within the office partition
About the Concept 3 Part Office Screen 1.8m high
The Concept acoustic screen partitioning range is unique in the fact that each panel accepts up to 3 fabric colours. Choose all 3 sections to have the same colour or mix and match the fabric choices to create a bespoke colour combination.
Other ways to customize the acoustic partitioning includes the choice of 3 frame colours. The frame is a powder coated aluminum, available in black, white or silver and complimented with matching stability feet. Designed with a raised shape, the stability feet are trip and wheel chair friendly.
To elevate the design, the frame has a built in optional linking detail. Each acoustic screen partition is supplied with a flexible inking strip. The strip fits into the frame and securely connects a range of Concept panels together. Flex and move the screens to create corners and angles to achieve the layout needed.
1800mm high covers approximately 5.9ft which is universally an effective height to close a space for many reasons. The right height paired with an acoustic foam will expertly reduce office noise from the loudest of spaces. Reduced noise can have a positive effect on the space and promote a happy and healthy workspace.
What are the benefits?
- Accepts 3 fabrics per screen
- Reduces office noise
- 3 frame colours available
- Made to order
- Linkable screen design
All office screens are made in the UK, by Rap Industries.
Product specifications for the Concept Acoustic Office Screen range.
Frame Measurements
Frame thickness - 28mm
Frame width - (side bars) - 50mm / (Top & bottom bar) - 22mm
Acoustic screen thickness (Core, foam & fabric) - 42mm
Foot slots in the frame are 290.5mm in from each end (Varied on screens 800mm W & smaller)
Materials
Frame - Powder coated aluminium
Stability feet - Steel
*stability feet are trip and wheelchair friendly
Feet raise the screen by 25mm and protrude 230mm from either side of the screen
Castor wheels (upgrade) Raise screen by 77mm & protrude 255mm each side of screen
Internal - 18mm solid core
Foam - 12mm fire retardant acoustic foam
Linking strips - Flexible PVC
Fire Safety Elements
Foam
12mm Combustion Modified Foam BS 5852-2: using ignition Source 5 Crib
Chipboard
Surface spread of Flames Class 2 tested to BS479-7
MDF
Surface spread of Flames Class 2 tested to BS479-7
Plastic Components
Manufactured using non-flammable, self-extinguishing plastic.
Aluminium
Extrusions has a melting of 660°C and is not considered to be a fire hazard.
Steel
Components are not considered to be a fire hazard.
Fabric Options
Woven Fabric
Woven Collection has been tested to BS 5867-2: 2008 & BS 7176 2007
Universe Fabric
Universe Collection has been tested to BS 5867-2: 2008 Type B
